SIMPLE TO USE:
Power On/Off: Press & hold right button Start Recording: Press left button Pause/Continue: Press left button End Recording: Press & hold left button Sync Data: Press right button

SENSOR CONNECTION & SETUP:
Download XOSS app from either the Apple App Store or Google Play, phone requires Bluetooth 4.0 or later. Press and hold both buttons simultaneously, sensor icon will start to flash which indicates searching. XOSS will automatically connect active sensors nearby. After pairing the corresponding icon will stop flashing. Press left button again to enter setting mode.

P1: Tyre Circumference Setting (mm)
P2: Metric/Imperial Unit Setting
P3: Time Zone Setting

Press left button to set number or option and press right button to switch between them. After setup is complete, press and hold the right button to exit setting mode. XOSS uses GNSS technology (GPS, Beidou, GLONASS & Galileo satellite systems) to achieve a strong reliable signal and pin point accuracy.

When the device is turned on, the GPS icon in the upper left corner will flash, indicating that the computer is searching for a satellite signal. Please do this outside ensuring the sky above is unobstructed.

INCLUDES: Micro USB cable and bicycle mount with rubber O-rings.

MOUNT INSTALLATION GUIDE:
1. Place rubber pad on the back of mount.
2. Use rubber O-rings to secure the mount to handlebar. Cross tie the mount with the rubber O-rings.
3. Align tabs on back of computer with the mount notches, press down slightly and rotate computer 90˚ to lock it in place.
